ASME SA 213 Stainless Steel Seamless Pipes
ASME SA 213 / SA 213M covers seamless ferritic and austenitic alloy-steel boiler, superheater, and heat-exchanger tubes. For stainless steel tubing supply, the most common grades include TP304, TP304L, TP316, TP316L, TP321, TP347, and other heat- and corrosion-resistant grades.
These seamless tubes are widely used in boilers, condensers, heat exchangers, pressure vessels, power plants, petrochemical equipment, and other high-temperature or corrosive service conditions where reliable dimensional accuracy and material consistency are required.
Specification of ASME SA213 / ASME SA213M Stainless Steel Seamless Pipes:
Item | Specification |
Standard | ASME SA213 / ASME SA213M |
Product Name | Stainless Steel Seamless Tubes |
Product Type | Seamless boiler tubes, superheater tubes, heat exchanger tubes |
Material Type | Austenitic stainless steel / Ferritic alloy steel |
Common Stainless Steel Grades | TP304, TP304L, TP316, TP316L, TP321, TP347, TP347H, TP310S |
Manufacturing Process | Cold drawn / Cold rolled / Hot finished |
Outside Diameter | 6.0 mm – 127.0 mm |
Wall Thickness | 0.5 mm – 12.0 mm |
Length | Up to 18 meters or as required |
Form | Straight tubes |
Delivery Condition | Solution annealed / Heat treated as per standard |
Surface Finish | Annealed and pickled, bright annealed |
Ends | Plain ends |
Testing | Chemical analysis, tensile test, hardness test, flattening test, flaring test, hydrostatic or nondestructive electric test |
Inspection Documents | MTC, EN 10204 3.1 / 3.2 upon request |
Application | Boilers, superheaters, heat exchangers, condensers, pressure equipment |
Why Choose ASME SA213 / ASME SA213M Stainless Steel Seamless Pipes?
Seamless structure for high pressure and temperature service
Good corrosion resistance in industrial and chemical environments
Suitable for boiler, superheater, and heat exchanger applications
Available in a wide range of stainless steel grades
Good dimensional tolerance and surface quality
Mill test certificates and third-party inspection available
Grades of ASME SA213 / ASME SA213M Stainless Steel Seamless Pipes:
TP304 / TP304L
TP316 / TP316L
TP321
TP347 / TP347H
TP310S
Other grades upon request
Application of ASME SA213 / ASME SA213M Stainless Steel Seamless Pipes:
Boiler systems
Superheater systems
Heat exchangers
Condensers
Petrochemical processing equipment
Power generation equipment
Inspection & Tests of ASME SA213 / ASME SA213M Stainless Steel Seamless Pipes:
Chemical composition analysis
Mechanical property testing
Flattening test
Flaring test
Hardness test
Hydrostatic test or non-destructive electric test
PMI testing available upon request
EN 10204 3.1 / 3.2 certificate available upon request
Package of ASME SA213 / ASME SA213M Stainless Steel Seamless Pipes:
These stainless steel seamless pipes and tubes are typically packed in seaworthy export packaging to ensure safe transportation and long-distance delivery.
Depending on the product size and customer requirements, the pipes or tubes are bundled with protective straps, packed in wooden cases, plywood cases, or hexagonal bundles, with both ends protected by plastic caps where applicable.
Each package is clearly labeled with grade, size, standard, heat number, and shipment details for full traceability. Waterproof wrapping, woven bags, and anti-rust protection can also be provided to ensure the materials arrive in good condition during ocean shipment and storage.
FAQ:
Answer: ASME SA 213 is mainly used for seamless boiler tubes, superheater tubes, and heat exchanger tubes in high-temperature and pressure service.
Answer: SA 213 is mainly for heat exchanger, boiler, and superheater tubing, while SA 312 covers stainless steel seamless and welded pipe for general corrosive and high-temperature service.
Answer: Yes. TP316L is one of the common grades supplied under ASME SA 213.
